產品系列 : 音響器材
產品型號 : MA 5000i
產品名稱 : 功率擴大機
| Frequency Response： | ± 0.25dB |
| Signal to Noise Ratio： | > 112dB |
| THD： | < 0.1% |
| THD+Noise： | < 0.1%, 20Hz to 20kHz |
| Intermodulation Distortion： | < 0.35% |
| Damping Factor： | > 5000 |
| Crosstalk： | > 80dB |
| Common Mode Rejection： | > 70dB Typical |
| DC Output Offset： | < ±3mV |
| Input Impedance： | 20kΩ balanced, 10kΩ unbalanced |
| Maximum Input Level： | +20dBu Typical |
| Load Impedance： | Stereo: 1/2/4/8/16Ω; Bridge: 2/4/8Ω |
| Input Sensitivity： | 1.4Vrms, 32dB gain, 26dB gain |
| Voltage Gain： | 39.3dB to 24.5dB |
| Required AC Mains (+/- 10%)： | Universal AC input, 100-240VAC, 50/60Hz |
| Dimensions： | 19" x 3.5" x 16.2" (48.3 cm x 8.9 cm x 41.1 cm) |
| Net Weight： | 28 lbs (12.7 kgs) |
| Shipping Weight： | 36 lbs (16.3 kgs) |
| IEC Power Connector： | 20A |
| Power Matrix | ||||||||
| Model | Channels | 20mS BURST | 20Hz-20kHz | 1kHz | 4Ω Dual | 8Ω Dual | 4Ω Bridged | 8Ω Bridged |
| 5000i | 2 | 3000W | 2000W | 2000W | 2500W | 1250W | 4000W | 5000W |
| 9000i | 2 | 4700W | 2800W | 2800W | 3500W | 1500W | 5600W | 7000W |
| 12000i | 2 | 6000W | 3750W | 3750W | 4500W | 2100W | 7500W | 9000W |
- The Macro-Tech i Series continues the Macro-Tech legacy of unparalleled sonic accuracy and detail, putting sound quality above all else
- Patented, cutting-edge Class-I circuitry gets more power out of an amplifier with less waste
- Rugged construction ensures that all Macro-Techs are built to withstand years of abuse on the road
- Global Power Supply — designed to deliver maximum power no matter what country you work in
- Built-in load, line voltage, input and output monitoring
- Standard Ethernet networking via System Architect® lets system operators monitor and control the amplifier from any location
