產品系列 : 音響器材
產品型號 : X15 HiQ
產品名稱 : 15吋舞台監聽喇叭
| Description | Active 2-way coaxial enclosure, controlled and amplified by LA4X / LA8 |
| Usable bandwidth(-10 dB) | 55 Hz - 20 kHz ([X15] preset) |
| Maximum SPL1 | 138 dB ([X15] preset) |
| Nominal directivity | Vertical: 60° Horizontal: 40° |
| Monitoring angle2 | 35° without risers 55° with risers |
| Transducers | LF: 1 × 15" neodymium, bass-reflex, laminar vents HF: 1 × 3" neodymium compression driver, ellipsoid waveguide |
| Nominal impedance | LF: 8 Ω HF: 8 Ω |
| Connectors | IN: SpeakON® LINK: SpeakON® |
| Rigging and handling | 2 × handles DIN580-compatible M8 threaded insert 4 × M10 threaded inserts 2 × 35 mm pole sockets |
| Weight (net) | 21 kg / 46.2 lb |
| Cabinet | First grade Baltic birch and beech plywood |
| Finish | Dark grey brown Pantone® 426C Custom RAL® code on special order |
| IP | IP43 |
- Power (SPL) in beamwidth and acoustic isolation
- High immunity to feedback
- Narrow ellipsoid directivity of 40° x 60°
- Low profile and weight for integration and handling
- Rugged build
- Active design with low latency preset
