產品系列 : 音響器材
產品型號 : VRX915M
產品名稱 : 15吋二音路舞台監聽喇叭
| Power Rating: | 800 W / 1600 W / 3200W |
| Frequency Range: | 60 Hz - 20 kHz |
| Dimensions (H x W x D): | 629 mm x 432 mm x 324 mm |
| Frequency Response: | 70 Hz - 20 kHz |
| Coverage Pattern: | 50° x 90° nominal |
| Crossover Modes: | Passive / Bi-amp |
| Crossover Frequency: | 1.1 kHz |
| System Maximum SPL: | 127 dB SPL continuous (133 dB SPL peak) |
| System Sensitivity (1w @ 1m): |
98 dB SPL |
| LF Driver: | 1 x JBL 2265H 380 mm (15 in) Differential Drive® woofer 8 Ohms |
| HF Driver: | 1 x JBL 2453H-SL, 38 mm (1.5 in) exit compression driver, 100 mm (4 in) voice coil and neodymium magnet |
| Nominal Impedance: | 8 ohms |
| Active Tunings: | Tunings available at www.jblpro.com |
| Enclosure: | Symmetrical stage monitor, 15/18 mm, plywood |
| Finish: | Black DuraFlex™ finish |
| Grille: | Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing |
| Input Connectors: | Neutrik® Speakon® NL-4 (x2), one on each end |
| Net Weight: | 21 kg (46.0 lb) |
- Compact and low-profile for minimal obstruction of audience sightlines
- 50° x 90° nominal coverage
- Bi-amplified or full-range passive operation
- Differential Drive® woofer with neodymium magnet for high power capacity and very light weight
- 4" (voice coil) diameter compression driver with neodymium magnet
